ACTFLEX 906 WPU
Class III Tested | 500%+ Elongation | Direct-Stick Tiling
Single-component water-based polyurethane membrane for wet areas and protected external areas beneath tiles and screeds.
Independent reports to AS/NZS 4858:2004 (251-5) and AS 4654.1:2012 (251-3) record passes in 50-cycle movement at 4 mm, water immersion, detergent immersion and heat ageing. As a system with ACTFLEX BIOSET it passed AS ISO 13007.5 at 1.128 MPa initial and 1.293 MPa heat-aged adhesion. Its non-slump body builds evenly on walls and floors, and at 35 g/L VOC it rolls on in ventilated internal spaces without solvent management. Use it in bathrooms, laundries, podiums, parapets, façades and pedestal-paver systems, installed to AS 3740:2021 and AS 4654.2. Not for permanent UV exposure, pools, planters, potable water or negative pressure.
specs
Technical Specifications.
Waterproof Time:
72 hours after final coat (full cure).
Coverage:
8–10 m² per 20 kg pail at 1.2 mm total DFT; two coats
Usable period after opening:
Touch dry time minimum:
Tack-free: 6 h at 25°C, 50% RH
Vapour Pressure @ 25°C:
Application Temperature:
10°C-26°C
Shelf Life:
12 months
Membrane
Classification:
Class III
Colour:
Grey
Tack Free Time:
6 hours @ 25°C
Recoat Time:
6–8 h; max. 48 h at 25°C, 50% RH
Elongation at Break:
517% (AS/NZS 4858); 518% (AS 4654.1)
Recommended
Thickness:
Walls and floors: minimum 1.2 mm total DFT, minimum two coats (approx. 0.6 mm DFT per coat).
Chemical
Resistant:
Full Cure:
3 days @ 25°C, 50% RH
Chemical Base:
Water-based polyurethane-modified polymer
Cure Mechanism:
Water evaporation
Tear Propagation
Resistance:
Service
Temperature:
Solids Content:
73% ± 2%
Bond Strength:
30.37 N (ASTM C794, EP250-primed concrete)
Density:
Relative density: 1.35–1.50
Compressive
Strength:
Flow:
Acceptance of Cyclic Movement:
Dimensional Stability:
Control Elongation at Break:
Control Tensile Strength:
4.26 MPa (AS/NZS 4858); 3.54 MPa (AS 4654.1)
Water Immersion Elongation at Break:
Water Immersion Tensile Strength:
Detergent Immersion Elongation at Break:
Detergent Immersion Tensile Strength:
Heat Aging Elongation at Break:
Heat Aging Tensile Strength:
Field Seam Strength:
Temperature Resistance:
Water Vapour Transmission
Water Vapour Transmission:
Application Method:
VOC Content:
35 g/L (ASTM D3960 / D2369)
Mixing Ratio:
Viscosity:
Storage Temperature:
Flash Point:
UV Resistance:
Hydrostatic Pressure Resistance:
Water Vapour Transmission Rate (WVTR):
Abrasion Resistance:
Bacterial/Algae Resistance:
Application Time:
Environmental Impact:
Packaging Sizes:
Hardness:
Adhesion to Substrate:
Appearance After Curing:
Clean-up Requirements:
Certification Standards:
calculator
Coverage Calculator.
Based on a manufacturers average recommended coverage of 8–10 m² per 20 kg pail at 1.2 mm total DFT; two coats
Required:
223 kg
pdfs
Product Documentation.
Safety Data Sheet 2 (PDF Download)
Technical Drawings (PDF Download)
3d
Application Model


Available in (sizes)
5 kg and 20 kg pails
